Construction Project Funding Identification Signs

C47A (CA) sign C47B (CA) sign

Use the Construction Project Funding Identifications signs, C47A(CA) (shown on the left) and the C47B(CA) sign (shown on the right), for non-SB1 or non-Clean California funded projects with an estimated cost of at least $750,000 and at least 50 working days, not including plant establishment or permanent erosion control establishment working days. Do not use for a seal coat, surfacing, or seismic projects.

Formats of these two signs are flexible to include federal, state and/or local agency funding sources. Information on the sign should include year of completion, and type of project, such as:

  • Highway Construction
  • Highway Repair
  • Highway Improvement
  • Bridge Construction
  • Bridge Repair
  • Roadside Work

Available sizes:

  • Freeway & Expressway: 132” x 78” (11 ft x 6.5 ft)
  • Conventional Highways: 96” x 60” (8 ft x 5 ft)
  • Local Roadways: 48” x 30” (4 ft x 2.5 ft)

C48 (CA) sign C49 (CA) Clean CA PFI sign
The C48 (CA) sign (shown on the left) is approved for use on all SB1 funded projects. The C49 (CA) sign (shown on the right) is now approved for use on all Clean California funded projects. These signs can be used regardless of total contract cost or number of work days for SB1 or Clean California funded projects. The sign comes in three sizes:

  • Freeway & Expressway: 132” x 78” (11 ft x 6.5 ft)
  • Conventional Highways: 96” x 60” (8 ft x 5 ft)
  • Local Roadways: 48” x 30” (4 ft x 2.5 ft)

C48 (CA) and C49 (CA) formats are flexible to include federal, state, and/or local agency sources.

C48 (CA) sign with logos
Up to four additional funding agency pictographs may be added to the sign for projects with local funds to recognize city, county, and regional municipal planning organizations as funding partners identified by the project manager. Pictographs must be smaller than the SB1 or Clean California logo (not any taller than twice the maximum capital letter height displayed on the sign), and the SB1 or Clean California logo must be the prominent, central graphic on the sign.

C49A (CA) Clean CA PFI sign
For projects funded by both SB1 and Clean California, use the C49A (CA) sign (shown above). The C49A (CA) sign can also be used regardless of total contract cost or number of work days, but other federal, state, and local agency sources shall not be included.

CA Sign Specification Drawings and Artwork

File Name Date
C47A (CA) (PDF) Construction Project Funding Identification Sign 8-9-19
C47B (CA) (PDF) Construction Project Funding Identification Sign 8-9-19
C48 (CA) (PDF) Construction Project Funding Identification Sign (for SB1) 8-9-19
C49 (CA) (PDF)
Construction Project Funding Identification Sign (for Clean California)
10-20-21
C49A (CA) (PDF)
Construction Project Funding Identification Sign (for Clean California and SB1) 10-20-21
SB1 Logo (PDF) SB1 Logo 7-20-17
SB1 Logo (AI) SB1 Logo (CMYK vector .ai) 7-20-17
Clean CA (PNG) Clean CA Logo (.png) 10-20-21
Clean CA (EPS) Clean CA Logo (CMYK vector .eps) 10-20-21
BWZA (PDF) Be Work Zone Alert logo (PDF) n/a
BWZA (JPG) Be Work Zone Alert logo (CMYK .jpg) n/a
BWZA (AI) Be Work Zone Alert logo (CMYK vector .ai) n/a

For further assistance, please contact Sarah Horn at sarah.horn@dot.ca.gov.
